HYDRAULIC HOSE
- HYDRAULIC HOSE
- In response to any types of applications, we supply very various spiral hose products to our customers.
This product line is highly appropriate to all types of applications of hose products, including high and low pressure varied industrial fixed type applications and on/off highway mobile applications.
Our HYDRAULIC HOSE products, providing maximum durability and continuing performance, are designed to make them fit to needs of any industries such as construction equipment, agricultural machinery and shipbuilding.
 |
 |
 |
 |
 |
 |
 |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number |
DN | Hose I.D. |
Hose O.D. |
Maximum Operating Pressure |
Minimum Burst Pressure |
Minimum Bend Radius |
Weight | ||||||
| mm | in | mm | in | bar | psi | bar | psi | mm | in | kg/m | lb/ft | ||
| EC110-04* | 6 | 6,4 | 0.25 | 14,1 | 0.56 | 225 | 3,250 | 900 | 13,000 | 100,0 | 3.99 | 0.22 | 0.15 |
| EC110-05 | 8 | 7,9 | 0.31 | 15,7 | 0.62 | 215 | 3,125 | 860 | 12,500 | 115,0 | 4.53 | 0.26 | 0.17 |
| EC110-06* | 10 | 9,5 | 0.38 | 18,1 | 0.71 | 180 | 2,600 | 720 | 10,400 | 130,0 | 5.12 | 0.33 | 0.22 |
| EC110-08* | 12 | 12,7 | 0.50 | 21,4 | 0.84 | 160 | 2,300 | 640 | 9,200 | 180,0 | 7.09 | 0.41 | 0.28 |
| EC110-10 | 16 | 15,9 | 0.62 | 24,5 | 0.96 | 130 | 1,900 | 520 | 7,600 | 200,0 | 7.87 | 0.47 | 0.32 |
| EC110-12* | 19 | 19,0 | 0.75 | 28,5 | 1.12 | 105 | 1,525 | 420 | 6,100 | 240,0 | 9.45 | 0.59 | 0.40 |
| EC110-16* | 25 | 25,4 | 1.00 | 36,6 | 1.44 | 88 | 1,275 | 352 | 5,100 | 300,0 | 11.81 | 0.87 | 0.58 |
| EC110-20 | 31 | 31,8 | 1.25 | 44,8 | 1.76 | 63 | 925 | 252 | 3,700 | 420,0 | 16.54 | 1.20 | 0.81 |
| EC110-24 | 38 | 38,1 | 1.50 | 52,1 | 2.05 | 50 | 725 | 200 | 2,900 | 500,0 | 19.69 | 1.40 | 0.94 |
| EC110-32 | 51 | 50,8 | 2.00 | 65,5 | 2.58 | 40 | 580 | 160 | 2,320 | 630,0 | 24.80 | 1.91 | 1.28 |
| EC210-04* | 6 | 6,4 | 0.25 | 15,7 | 0.62 | 400 | 5,800 | 1600 | 23,200 | 100,0 | 3.94 | 0.38 | 0.26 |
| EC210-05 | 8 | 7,9 | 0.31 | 17,3 | 0.68 | 350 | 5,100 | 1400 | 20,400 | 115,0 | 4.53 | 0.43 | 0.29 |
| EC210-06* | 10 | 9,5 | 0.38 | 19,7 | 0.78 | 330 | 4,800 | 1320 | 19,200 | 130,0 | 5.12 | 0.54 | 0.36 |
| EC210-08* | 12 | 12,7 | 0.50 | 23,0 | 0.91 | 275 | 4,000 | 1100 | 16,000 | 180,0 | 7.09 | 0.64 | 0.43 |
| EC210-10 | 16 | 15,9 | 0.62 | 26,2 | 1.03 | 250 | 3,650 | 1000 | 14,600 | 200,0 | 7.87 | 0.75 | 0.50 |
| EC210-12* | 19 | 19,0 | 0.75 | 30,1 | 1.09 | 215 | 3,125 | 860 | 12,500 | 240,0 | 9.45 | 0.93 | 0.62 |
| EC210-16* | 25 | 25,4 | 1.00 | 38,9 | 1.53 | 165 | 2,400 | 660 | 9,600 | 300,0 | 11.81 | 1.29 | 0.87 |
| EC210-20 | 31 | 31,8 | 1.25 | 49,5 | 1.95 | 125 | 1,800 | 500 | 7,200 | 420,0 | 16.54 | 1.89 | 1.27 |
| EC210-24 | 38 | 38,1 | 1.50 | 55,9 | 2.20 | 90 | 1,300 | 360 | 5,200 | 500,0 | 19.69 | 2.10 | 1.41 |
| EC210-32 | 51 | 50,8 | 2.00 | 68,6 | 2.70 | 80 | 1,150 | 320 | 4,600 | 630,0 | 24.80 | 2.76 | 1.85 |
